Key Benefits:

  • Default Wattage: 60W, 120W
  • IP65 rated
  • Easy installation and maintenance
  • Corrosion and rust proof
  • Photocell included
  • Full cut-off shield option
  • 50,000 hours lifetime
Contact Us

Pay with total security
40+ Years of Expertise
Wholesale Pricing Advantage
Wide Product Range
Built for Durability
Trusted by Professionals

Product Description & Technical Specifications

LEDWP040UNV-1 • LOC-WP-MW(20/25/40/60)3K-4K-5K

WATTAGE SELECTABLE
CCT
LUMENS
EFFICACY
VOLTAGE
CRI
POWER FACTOR
THD
REPLACES
20W
5000K
2,700LM
135lm/W
120-277V
70
0.9
20%
35W-50W HID
25W
5000K
3,375LM
135lm/W
120-277V
70
0.9
20%
70W-100W HID
40W
5000K
5,400LM
135lm/W
120-277V
70
0.9
20%
150W-175W HID
60W
5000K
8,100LM
135lm/W
120-277V
70
0.9
20%
175W-200W HID

LEDWP060/080/100/120-CCT • LOC-WP-MW(60/80/100/120)3K-4K-5K

WATTAGE SELECTABLE
CCT
LUMENS
EFFICACY
VOLTAGE
CRI
POWER FACTOR
THD
REPLACES
60W
5000K
8,286LM
138.1lm/W
120-277V
74
0.967
8%
175W – 200W HID
80W
5000K
11,048LM
138.1lm/W
120-277V
74
0.967
8%
200W – 250W HID
100W
5000K
13,810LM
138.1lm/W
120-277V
74
0.967
8%
320W – 375W HID
120W
5000K
16,572LM
138.1lm/W
120-277V
74
0.967
8%
400W – 450W HID
Download Datasheet
LED Multi Watt Wall Pack Light Family 50K Series

Key Features & Benefits

Construction

Heavy die-cast aluminum alloy housing with bronze powder-coated finish. Glass lens

OPTICAL SYSTEM

Lumileds LUXEON 3030 2D LED chips. High quality tempered glass optics. 120° beam angle.

WARRANTY

1-year limited warranty. Actual performance may differ as a result of end-user environment and application.

ELECTRICAL

Available as 120-277V input. -40°C to 40°C, -40°F to 104°F , 480V Option Available

INSTALLATION & MOUNTING

Wall Mounting with quick mount back plate for easy installation.

CONTROLS & DIMMING

0-10V dimming comes standard. Photocell is included.
